Granule,Sugar,Coffee,Peanut,Bean Packing Machine

Volumetric Cup System for GranuleEntry level for auto-packing system with high work efficiencyReplacement for sealer to save labor costsApplication: For sugar, rice, salt, tea, potato chips, ground coffee, snack food etc granule products & free flowing powder Principal Features:Form, fill & seal system and volumetric cup dosing system integrated, compact system, electric drivingComputerized control system with 5 inch LCD with descriptive fault indicatorPhotocell for film length registered and automatic adjustment in 3 bagsVarious types of laminated films namely PE/BOPP, CPP/BOPP, CPP/PET, PE/NYLON, aluminum foil based compatibleAll product contact parts in #304 stainless steel or food grade plasticOutput countingOption:Hot Stamping Date CoderPlexiglass Safety Guard#304 Stainless Steel FrameProduct contact parts to be S/S316 Technical Specification:Bag Type3 Side SealWorking MotionIntermittentWorking Speed40-110 bags/minVolumetric Cup Volume5-120 mlBag Length30 to 150 mm ( 1.18 o 5.91 in)Bag Width25 to 135 mm ( 0.98 to 0.31 in) Change FormerReel Width≤270 mm ( 10.63 in)Film Thickness0.03 0.08mmReel Outer Dia.≤400mm (15.7in)Reel Core Dia.75mm (2.9in)VoltageAC 220V 50Hz, 1 phrasePower Consumption1.2 kwMachine DimensionL 850 mm x W 650 mm x H 1650 mm(H 33.46 in x W 25.59 in x H 64.96 in)Shipping DimensionL 1120 mm x W 780 mm x H 1720 mm (H 44.09 in x W 30.71 in x H 67.72 in)Machine Weight280 kgs
