oil, ketchup, sauce,jam and ointment Packing Machi

Piston pump system for liquid in 4 sides seal with 4 inesEntry level for auto-packing system with high work efficiencyReplacement for sealer to save labor costsApplication: For shampoo, cream, ketchup, liquor, oil, jelly etc liquid & paste products seal in 4 side seals at 4 lines. Principal Features:Form, fill & seal system and piston pump dosing system integrated, compact system, electric driving Computerized control system with 5 inch LCD with descriptive fault indicator Photocell for film length registered and automatic adjustment in 3 bags Various types of laminated films namely PE/BOPP, CPP/BOPP, CPP/PET, PE/NYLON, aluminum foil based compatible All product contact parts in #304 stainless steel or food grade plastic Output counting Option:Hot Stamping Date Coder Plexiglass Safety Guard #304 Stainless Steel Frame Product contact parts to be S/S316 Technical Specification:Bag Type4 Side Seal at 4 LinesWorking MotionIntermittentWorking Speed60 - 140 bags/minPiston Filling Range3 12 mlBag Length40 to 80 mm ( 1.57 to 3.15 in)Bag Width20 to 60 mm ( 0.79 to 2.36 in)Reel Width≤240 mm ( 9.45 in)Film Thickness0.03 0.08mmReel Outer Dia.≤400mm (15.7in)Reel Core Dia.75mm (2.9in)VoltageAC 220V 50Hz, 1 phrasePower Consumption2.6 kwMachine DimensionL 950 mm x W 750 mm x H 1650 mm(H 33.46 in x W 25.59 in x H 64.96 in)Shipping DimensionL 1250 mm x W 850 mm x H 1800 mm (H 49.21 in x W 33.46 in x H 70.87 in)Machine Weight420 kgs
